NGC2170 and Several Other Objects in Monoceros
Imaged from Nova Scotia, Winter, 2026
While entitled NGC 2170, that object is the smallest and least conspicuous object in this busy field. The largest, and most prominent is actually the HII region LBN999. Several VdB reflection features are also in this field as can be identified from the annotated frame. The Ha emission associated with the VdB objects has been deemphasized in processing to preserve the reflection nebulosity.
HaRGB Combination
| Data | |
|---|---|
| Altitude at culmination 39° | |
| Minimum Airmass Value (sec z) 1.6 | |
| Taking Camera SBIG STL-11002XM | Nova Scotia Winter, 2026 skies ~mag 6.6 - CCD @ -20C |
| Imaging OTA | AGO 14.5" iDK |
| Equivalent focal length and ratio | 2465mm @ f/6.7 |
| Mount | Astro-Physics 1600GTO |
| Guiding | PHD2/ONAG/Ultrastar Pro |
| HaRGB Total Integration Time 19hrs 10mins | Ha 14x30 min, R24x10 min G24x10 min, B25x10 min, Astrodon Gen 2 I series RGB and 5nm Ha Filters. All Binned 1X1 | Acquisition | Main Sequence Software-Sequence Generator Pro | Calibration and Stacking | Darks, Flats and Bias - Stacked and calibrated with PixInsight |
| Processed Feb, 2026 | PixInsight, Affinity Photo v.2.6.5 and Bob Franke's CCDBand-Aid |
Annotated Frame
